90 Degree 50 Pin IDC Male Champ Connector with Phosphor Bronze Pin Material

Name: 90 Degree 50 Pin IDC Male Champ Connector with Phosphor Bronze Pin Material
Brand: FUYCONN
Price: 1 USD

Buy cheap 90 Degree 50 Pin IDC Male Champ Connector with Phosphor Bronze Pin Material product

Place of Origin : China

Brand Name : FUYCONN

Certification : UL 94-V0, ROHS-certified, ISO 9001:2008, ISO 14001:2004

Model Number : FUY57151-2C-50P

MOQ : 10pcs

Price : Negotiable

Packaging Details : Vacuum Tray + Carton

Delivery Time : 7-10 days

Payment Terms : T/T or Paypal

Supply Ability : 1 million/ month

Product Name : Centronic Connector

Connector Type : IDC Crimping Connector

Pitch : 2.16mm

Gender : Male plug

no. of pin : 50pin 25pairs connector

Gold plating : 1U", 3U", 5U" ,10U", 15U", 30U"

Contact Material : Phosphore Bronze

Insulation Material : PBT

Contact Now

90 Degree 50 Pin IDC Male Champ Connector with Phosphor Bronze Pin Material

FUY57151A-50P 50 Pin 90 Degree Black Cover IDC Champ Type connector 50 Way Male Plug

90 Degree 50 Pin IDC Male Champ Connector with Phosphor Bronze Pin Material

Detail Description

Product Category: Centronic connector
Product Line: Champ Connector
Type: Centronic IDC Connector
Connector Style:Plug
Number of Terminal: 50 pin
Gender: Male
Insulator Color: Black
Insulator Material: PPO
Contact pin Material: Phosphor Bronze
Centerline = 2.16mm [0.085in]
Mounting Option: 90°Cable Outlet
Cover: Plastic Cover or No Cover both are available

Common Features

Designed for Cable-to-cable and cable-to-PC Board applications
Avilable in Plug & Socket Style
Terminal Option with various types
Connector and hood sold as complete assembly
Avilable in low profile hood style
Metal shell provides grounding and shielding capability
Mates with industry compatible connector

Product Features

Product Type:	Centronics IDC Connector
Product Line:	Champ Connector
Gender:	Male
Connector Style:	Plug
Certerline :	2.16mm(0.85in)
Number of Position:	50 pin
Contact Plating:	Gold Flash 1U", 3U", 5U" ,10U", 15U", 30U"
Insulator Color:	Black
Shielded:	Yes
Orientation:	90 Degree Cable Exit
Mating connector lock:	Screwlocks

Materials

Contact Material:	Phosphor Bronze
Insulator:	PBT
Housing Material:	Plastic

Electrical Character

Current Rating:	5Amp
Withstanding Voltage:	AC 1000v r.m.s
Insulation Resistance:	1000 Megohms Minimum at DC 500V
Contact Resistance:	25M∩ Max Mated
Operation Temperature:	-55°C to +105°C

Application

1, VDSL Teleccom Equipment
2, Computer Peripherals
3, Communication Equipment
4, RJ21 Cable
5, Cable to Panel
6, Cable to cable
7,Computer terminal
8,Telemetering
9,Test Equipment
10, Printer

Advantage

1,ROHS compliant, UL-approved
2,High quality, Competitive price
3,Quick delivery time
4,Free sample available in 2 days
